| Onderdeel nummer | AM-640480V2TZQW-TA7H |
| Merk | AMPIRE |
| Maat | 5.7 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 640×480 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 262K |
| Tegenlicht | 4S7P |
| Koppel | LVDS |
| paneel merk | AMPIRE |
| paneelmodel | AM-640480V2TZQW-TA7H |
| paneel grootte | 5.7" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 640(RGB)×480, VGA, 141PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 115.2(W)×86.4(H) mm |
| omlijsting openen | - |
| omtrek grootte | 127(W)×98.43(H) ×10.88(D) mm |
| oppervlak | - |
| helderheid | 850 cd/m² (Typ.) |
| contrast ratio | 1200:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | IPS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kleuren weergeven | 262K 60% NTSC |
| soort lamp | 4S7P WLED , 50K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | PCAP |
| paneel gewicht | - |
| sollicitatie | Industrial Outdoor High Brightness |
| signaal interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
