| Onderdeel nummer | AM-640480G2TNQW-A0H |
| Merk | AMPIRE |
| Maat | 5.7 |
| Sollicitatie | Industrial |
| Oplossing | 640×480 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 250:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AMPIRE |
| model | AM-640480G2TNQW-A0H |
| diagonale maat | 5.7 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 640(RGB)×480 [VGA] 141PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 115.2(H)×86.4(V) mm |
| omtrek afm. | 127(H)×98.43(V) ×7.8(D) mm |
| bezel gebied | 118.0(H)×89.2(V) mm |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 500 cd/m² (Typ.) |
| contrast ratio | 250:1 (Typ.) (TM) |
| richting bekijken | 12 o'clock |
| reactietijd | 50 (Typ.)(Tr+Td) |
| kijk hoek | 70/70/50/50 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K 50% NTSC |
| lichtbron | WLED , 20K hours , With LED Driver |
| gewicht | - |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (1 ch, 6-bit) , 20 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
