| Onderdeel nummer | AM-480272MGTZQW-02H |
| Merk | AMPIRE |
| Maat | 4.3 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 480×272 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | 5S3P |
| Koppel | Parallel |
| paneel merk | AMPIRE |
| paneelmodel | AM-480272MGTZQW-02H |
| paneel grootte | 4.3" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 480(RGB)×272, WQVGA, 128PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 95.04(W)×53.856(H) mm |
| omlijsting openen | 97.6(W)×56.0(H) mm |
| omtrek grootte | 105.6(W)×67.2(H) ×3.1(D) mm |
| oppervlak | - |
| helderheid | 1000 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | IPS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kleuren weergeven | 16.7M 51% NTSC |
| soort lamp | 5S3P WLED , Without Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | - |
| sollicitatie | Industrial Outdoor High Brightness Automotive Display |
| signaal interface | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
