| Onderdeel nummer | AM-480272HBTMQW-T00H |
| Merk | AMPIRE |
| Maat | 4.3 |
| Sollicitatie | Industrial |
| Oplossing | 480×272 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 250:1 |
| Kleuren | 16.7M |
| Tegenlicht | 7S1P |
| Koppel | Parallel |
| fabrikant | AMPIRE |
| modelnaam | AM-480272HBTMQW-T00H |
| scherm grootte | 4.3 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 480(RGB)×272 (WQVGA) 128PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 95.04 × 53.856 (H×V) |
| overzicht (mm) | 105.5 × 67.2 × 7.99 (H×V×D) |
| bezel gebied (mm) | 98.7 × 57.5 (H×V) |
| behandeling | - |
| luminantie | 250 cd/m² (Typ.) |
| contrast ratio | 250 : 1 (Typ.) (TM) |
| kijk hoek | 65/65/45/45 (Typ.)(CR≥10) |
| antwoord | 40 (Typ.)(Tr+Td) ms |
| goed zicht op | 6 o'clock |
| werk modus | TN, Normally White, Transmissive |
| kleuren diepte | 16.7M |
| tegenlicht | 7S1P WLED , 20K hours , No Driver |
| massa | - |
| gebruikt voor | Industrial |
| vernieuwingsfrequentie | 60Hz |
| touch screen | PCAP |
| signaal type | Parallel RGB (1 ch, 8-bit) , FPC 54 pins |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
