| Onderdeel nummer | AM-240320GTZQW-02H |
| Merk | AMPIRE |
| Maat | 2.8 |
| Sollicitatie | Mobile Phone |
| Oplossing | 240×320 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 450:1 |
| Kleuren | 65K |
| Tegenlicht | WLED |
| Koppel | CPU/RGB/SPI |
| merk | AMPIRE |
| model | AM-240320GTZQW-02H |
| diagonale maat | 2.8 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 240(RGB)×320 [QVGA] 141PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 43.2(H)×57.6(V) mm |
| omtrek afm. | 49(H)×67.5(V) ×4.9(D) mm |
| luminantie | 280 cd/m² (Typ.) |
| contrast ratio | 450:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 15/20 (Typ.)(Tr/Td) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedrijfsmodus | MVA, Normally Black, Transmissive |
| ondersteunende kleur | 65K 69% NTSC |
| lichtbron | WLED [3S2P] , With LED Driver |
| gewicht | TBD |
| ontworpen voor | Mobile Phone |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | CPU/RGB/SPI , 40 pins FPC |
| stroomvoorziening | 2.8V (Typ.) |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
