| Onderdeel nummer | AM-19201200GTZQW-30H |
| Merk | AMPIRE |
| Maat | 10.1 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1920×1200 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AMPIRE |
| model | AM-19201200GTZQW-30H |
| diagonale maat | 10.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1200 [WUXGA] 224PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 217.44(H)×135.9(V) mm |
| omtrek afm. | - |
| luminantie | 1000 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 50 (Max.)(Tr+Td) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedrijfsmodus | AHVA, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M 57% NTSC |
| lichtbron | WLED , 50K hours , W/O Driver |
| gewicht | - |
| ontworpen voor | Industrial Outdoor High Brightness |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (2 ch, 8-bit) , 45 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
