| Onderdeel nummer | AM-19201200FTZQW-00 |
| Merk | AMPIRE |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1920×1200 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| paneel merk | AMPIRE |
| paneelmodel | AM-19201200FTZQW-00 |
| paneel grootte | 10.1" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1920(RGB)×1200, WUXGA, 224PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 216.806(W)×135.504(H) mm |
| omlijsting openen | - |
| omtrek grootte | 227.72(W)×147.8(H) ×5.35(D) mm |
| oppervlak | - |
| helderheid | 380 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | AHVA, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 25 (Typ.)(Tr+Td) |
| kleuren weergeven | 16.7M 50% NTSC |
| soort lamp | WLED , 30K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | - |
| sollicitatie | Industrial |
| signaal interface | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
