| Onderdeel nummer | AM-19201200CTZQW-00 |
| Merk | AMPIRE |
| Maat | 10.1 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1920×1200 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| fabrikant | AMPIRE |
| modelnaam | AM-19201200CTZQW-00 |
| scherm grootte | 10.1 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1200 (WUXGA) 225PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 216.576 × 135.36 (H×V) |
| overzicht (mm) | 244.8 × 155.3 × 7 (H×V×D) |
| luminantie | 1000 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | AHVA, Normally Black, Transmissive |
| kleuren diepte | 16.7M 49% NTSC |
| tegenlicht | WLED , 50K hours , With LED Driver |
| massa | - |
| gebruikt voor | Industrial Outdoor High Brightness |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| Storage Temp.: -20 ~ 65 °C Operating Temp.: -20 ~ 65 °C |
