| Onderdeel nummer | AM-19201200B2TZQW-T06 |
| Merk | AMPIRE |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1920×1200 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| merk | AMPIRE |
| diagonale maat | 10.1 inch |
| pixel formaat | 1920(RGB)×1200 [WUXGA] 224PPI |
| actief gebied | 216.806(H)×135.504(V) mm |
| luminantie | 340 cd/m² (Typ.) |
| richting bekijken | Symmetry |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| ondersteunende kleur | 16.7M 53% NTSC |
| gewicht | - |
| frame rate | 60Hz |
| model | AM-19201200B2TZQW-T06 |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 230.12(H)×150.2(V) ×8.26(D) mm |
| contrast ratio | 800:1 (Typ.) (TM) |
| reactietijd | 25 (Typ.)(Tr+Td) |
| bedrijfsmodus | AHVA, Normally Black, Transmissive |
| lichtbron | WLED , 12K hours , With LED Driver |
| ontworpen voor | Industrial |
| aanraakpaneel | PCAP |
