| Onderdeel nummer | AM-19201200B1TZQW-T09 |
| Merk | AMPIRE |
| Maat | 10.1 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1920×1200 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| paneel merk | AMPIRE |
| paneel grootte | 10.1" |
| oplossing | 1920(RGB)×1200, WUXGA, 224PPI |
| weergavegebied | 216.806(W)×135.504(H) mm |
| omtrek grootte | 243.45(W)×155.2(H) mm |
| helderheid | 850 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 16.7M 53% NTSC |
| frequentie | 60Hz |
| gewicht | - |
| paneelmodel | AM-19201200B1TZQW-T09 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | - |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | Normally Black, Transmissive |
| reactietijd | 25 (Typ.)(Tr+Td) |
| soort lamp | WLED , 50K hours , With LED Driver |
| touch screen | PCAP |
| sollicitatie | Industrial Outdoor High Brightness |
