| Onderdeel nummer | AM-1280800P4TZQW-T00H |
| Merk | AMPIRE |
| Maat | 7.0 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1280×800 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| merk | AMPIRE |
| diagonale maat | 7.0 inch |
| pixel formaat | 1280(RGB)×800 [WXGA] 217PPI |
| actief gebied | 149.76(H)×93.6(V) mm |
| bezel gebied | 152.76(H)×96.6(V) mm |
| luminantie | 1275 cd/m² (Typ.) |
| richting bekijken | Symmetry |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| ondersteunende kleur | 16.7M 50% NTSC |
| gewicht | - |
| frame rate | 60Hz |
| model | AM-1280800P4TZQW-T00H |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 162.3(H)×107.9(V) ×11.76(D) mm |
| behandeling | - |
| contrast ratio | 800:1 (Typ.) (TM) |
| reactietijd | 35 (Typ.)(Tr+Td) |
| bedrijfsmodus | SFT, Normally Black, Transmissive |
| lichtbron | WLED [5S4P] , 50K hours , With LED Driver |
| ontworpen voor | Industrial Outdoor High Brightness |
| aanraakpaneel | PCAP |
