| Onderdeel nummer | AM-1280800J4TZQW-T00 |
| Merk | AMPIRE |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1280×800 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AMPIRE |
| model | AM-1280800J4TZQW-T00 |
| diagonale maat | 10.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×800 [WXGA] 149PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 216.96(H)×135.6(V) mm |
| omtrek afm. | 231(H)×150(V) ×8.8(D) mm |
| luminantie | 300 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 10/15 (Typ.)(Tr/Td) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedrijfsmodus | Normally Black, Transmissive |
| ondersteunende kleur | 16.7M |
| lichtbron | WLED [3S11P] , 15K hours , With LED Driver |
| gewicht | TBD |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | PCAP |
| interface-type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
