| Onderdeel nummer | AM-1024768Y2TZQW-A1H |
| Merk | AMPIRE |
| Maat | 10.4 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 900:1 |
| Kleuren | 16.2M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| paneel merk | AMPIRE |
| paneelmodel | AM-1024768Y2TZQW-A1H |
| paneel grootte | 10.4" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1024(RGB)×768, XGA, 123PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 211.2(W)×158.4(H) mm |
| omlijsting openen | 213.2(W)×160.4(H) mm |
| omtrek grootte | 236(W)×174.3(H) ×10.4(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 1000 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | IPS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kleuren weergeven | 16.2M |
| soort lamp | WLED , 30K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | TBD |
| sollicitatie | Industrial Outdoor High Brightness |
| signaal interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
