| Onderdeel nummer | AM-1024768V1TZQW-A0H |
| Merk | AMPIRE |
| Maat | 8.4 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AMPIRE |
| model | AM-1024768V1TZQW-A0H |
| diagonale maat | 8.4 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×768 [XGA] 152PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 170.8(H)×128.1(V) mm |
| omtrek afm. | 203(H)×145.5(V) ×8(D) mm |
| bezel gebied | 174.15(H)×131.2(V) mm |
| behandeling | - |
| luminantie | 1000 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedrijfsmodus | IPS, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M |
| lichtbron | WLED [6S6P] , 50K hours , With LED Driver |
| gewicht | - |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
