| Onderdeel nummer | AM-1024768R7TNQW-T00H |
| Merk | AMPIRE |
| Maat | 12.1 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | 9S3P |
| Koppel | LVDS |
| paneel merk | AMPIRE |
| paneel grootte | 12.1" |
| oplossing | 1024(RGB)×768, XGA, 105PPI |
| weergavegebied | 245.76(W)×184.32(H) mm |
| omtrek grootte | 279(W)×209(H) ×11.2(D) mm |
| helderheid | 510 cd/m² (Typ.) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K/16.7M |
| frequentie | 60Hz |
| paneel gewicht | - |
| signaal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| paneelmodel | AM-1024768R7TNQW-T00H |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | - |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 16 (Typ.)(Tr+Td) |
| soort lamp | 9S3P WLED , 50K hours , Without Driver |
| touch screen | PCAP |
| sollicitatie | Industrial |
