| Onderdeel nummer | AM-1024768R3TNQW-T00H |
| Merk | AMPIRE |
| Maat | 12.1 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | |
| merk | AMPIRE |
| model | AM-1024768R3TNQW-T00H |
| diagonale maat | 12.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×768 [XGA] 105PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 245.76(H)×184.32(V) mm |
| omtrek afm. | 279(H)×209(V) ×11.2(D) mm |
| luminantie | 300 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| richting bekijken | - |
| reactietijd | 16 (Typ.)(Tr+Td) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K/16.7M |
| lichtbron | WLED , 30K hours , With LED Driver |
| gewicht | - |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
