| Onderdeel nummer | AM-1024768FCTMQW-T00H |
| Merk | AMPIRE |
| Maat | 10.4 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 262K/16.2M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AMPIRE |
| model | AM-1024768FCTMQW-T00H |
| diagonale maat | 10.4 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×768 [XGA] 123PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 210.4(H)×157.8(V) mm |
| omtrek afm. | 238.6(H)×175.8(V) mm |
| luminantie | 280 cd/m² (Typ.) |
| contrast ratio | 1200:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 14/11 (Typ.)(Tr/Td) |
| kijk hoek | 88/88/88/88 (Typ.)(CR≥10) |
| bedrijfsmodus | Normally Black, Transmissive |
| ondersteunende kleur | 262K/16.2M 57% NTSC |
| lichtbron | WLED , 30K hours , With LED Driver |
| gewicht | - |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | PCAP |
| interface-type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
