| Onderdeel nummer | AM-1024600L2HMQW-T01H |
| Merk | AMPIRE |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AMPIRE |
| model | AM-1024600L2HMQW-T01H |
| diagonale maat | 10.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×600 [WSVGA] 117PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 222.72(H)×125.28(V) mm |
| omtrek afm. | 235(H)×145.8(V) ×9.8(D) mm |
| bezel gebied | 225.92(H)×128.48(V) mm |
| behandeling | - |
| luminantie | 800 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| richting bekijken | - |
| reactietijd | 4/12 (Typ.)(Tr/Td) |
| kijk hoek | 70/70/70/50 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K 47% NTSC |
| lichtbron | WLED [6S6P] , 50K hours , With LED Driver |
| gewicht | TBD |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | 4-wire Resistive Touch |
| interface-type | LVDS (1 ch, 6-bit) , 30 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -5 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
