| Onderdeel nummer | AM-1024600K7TMQW-T19H |
| Merk | AMPIRE |
| Maat | 7.0 |
| Sollicitatie | Industrial |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 700:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| merk | AMPIRE |
| diagonale maat | 7.0 inch |
| pixel formaat | 1024(RGB)×600 [WSVGA] 169PPI |
| actief gebied | 153.6(H)×90(V) mm |
| luminantie | 425 cd/m² (Typ.) |
| richting bekijken | 6 o'clock |
| kijk hoek | 75/75/70/75 (Typ.)(CR≥10) |
| ondersteunende kleur | 16.7M |
| gewicht | TBD |
| frame rate | 60Hz |
| model | AM-1024600K7TMQW-T19H |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 165.5(H)×104.44(V) ×10.81(D) mm |
| contrast ratio | 700:1 (Typ.) (TM) |
| reactietijd | 20/20 (Typ.)(Tr/Td) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| lichtbron | WLED [5S3P] , 30K hours , With LED Driver |
| ontworpen voor | Industrial |
| aanraakpaneel | PCAP |
