| Onderdeel nummer | AM-1024600DTZQW-TA6H |
| Merk | AMPIRE |
| Maat | 7.0 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AMPIRE |
| model | AM-1024600DTZQW-TA6H |
| diagonale maat | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×600 [WSVGA] 170PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 154.221(H)×85.92(V) mm |
| omtrek afm. | 164.9(H)×128(V) ×12.6(D) mm |
| luminantie | 850 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 13/15 (Typ.)(Tr/Td) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedrijfsmodus | IPS, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M 58% NTSC |
| lichtbron | WLED , 50K hours , With LED Driver |
| gewicht | - |
| ontworpen voor | Industrial Outdoor High Brightness |
| frame rate | 60Hz |
| aanraakpaneel | PCAP |
| interface-type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
