| Onderdeel nummer | AM-1024600DTZQW-TA0H |
| Merk | AMPIRE |
| Maat | 7.0 |
| Sollicitatie | Industrial |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| paneel merk | AMPIRE |
| paneel grootte | 7.0" |
| oplossing | 1024(RGB)×600, WSVGA, 170PPI |
| weergavegebied | 154.221(W)×85.92(H) mm |
| omtrek grootte | 184(W)×128(H) ×12.6(D) mm |
| helderheid | 425 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 16.7M 58% NTSC |
| frequentie | 60Hz |
| gewicht | - |
| paneelmodel | AM-1024600DTZQW-TA0H |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | - |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | IPS, Normally Black, Transmissive |
| reactietijd | 13/15 (Typ.)(Tr/Td) |
| soort lamp | WLED , 30K hours , With LED Driver |
| touch screen | PCAP |
| sollicitatie | Industrial |
