| Onderdeel nummer | AM-1024600DTZQW-A6H |
| Merk | AMPIRE |
| Maat | 7.0 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1024×600 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| fabrikant | AMPIRE |
| modelnaam | AM-1024600DTZQW-A6H |
| scherm grootte | 7.0 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 1024(RGB)×600 (WSVGA) 170PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 154.221 × 85.92 (H×V) |
| overzicht (mm) | 164.9 × 100 (H×V×D) |
| bezel gebied (mm) | 158 × 89.7 (H×V) |
| behandeling | Antiglare |
| luminantie | 1000 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| antwoord | 13/15 (Typ.)(Tr/Td) ms |
| goed zicht op | Symmetry |
| werk modus | IPS, Normally Black, Transmissive |
| kleuren diepte | 16.7M |
| tegenlicht | WLED , 50K hours , With LED Driver |
| massa | - |
| gebruikt voor | Industrial Outdoor High Brightness |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
