| Onderdeel nummer | AC121SA04 |
| Merk | Mitsubishi |
| Maat | 12.1 |
| Sollicitatie | Industrial |
| Oplossing | 800×600 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | Mitsubishi |
| model | AC121SA04 |
| diagonale maat | 12.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×600 [SVGA] 82PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 246(H)×184.5(V) mm |
| omtrek afm. | 260.5(H)×203(V) ×10(D) mm |
| bezel gebied | 249.0(H)×187.5(V) mm |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 500 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| richting bekijken | 6 o'clock |
| reactietijd | 10/15 (Typ.)(Tr/Td) |
| kijk hoek | 80/80/60/80 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K/16.7M 72% NTSC |
| lichtbron | WLED , 70K hours , With LED Driver |
| gewicht | 580g (Typ.) |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
