| Onderdeel nummer | A062EAN01.0 |
| Merk | AUO |
| Maat | 6.2 |
| Sollicitatie | Home Appliance |
| Oplossing | 1280×720 |
| Samenstelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | |
| merk | AUO |
| diagonale maat | 6.2 inch |
| pixel formaat | 1280(RGB)×720 [WXGA] 237PPI |
| actief gebied | 137.088(H)×77.112(V) mm |
| bezel gebied | - |
| luminantie | 0 cd/m² |
| richting bekijken | Symmetry |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| plaatdikte | 0.20+0.20 mm |
| ondersteunende kleur | 16.7M 71% NTSC |
| gewicht | TBD |
| frame rate | 60Hz |
| d-ic detail | COG Suggest HX8394-F |
| omgeving | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
| model | A062EAN01.0 |
| type | a-Si TFT-LCD , CELL |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 145.338(H)×81.712(V) ×0.63(D) mm |
| behandeling | Antiglare, Hard coating (3H) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| reactietijd | 15/12 (Typ.)(Tr/Td) |
| bedrijfsmodus | AHVA, Normally Black, Transmissive |
| doorlaatbaarheid | 4.64% (Typ.)(with Polarizer) |
| lichtbron | No B/L |
| ontworpen voor | Home Appliance |
| aanraakpaneel | Without |
