| Onderdeel nummer | A050EAT01.0 |
| Merk | AUO |
| Maat | 5.0 |
| Sollicitatie | Industrial |
| Oplossing | 1280×720 |
| Samenstelling | a-Si TFT-LCD, Assemb |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | MIPI |
| merk | AUO |
| model | A050EAT01.0 |
| diagonale maat | 5.0 inch |
| type | a-Si TFT-LCD, Assembly |
| pixel formaat | 1280×720(RGB) [WXGA] 294PPI |
| configuratie | RGB Horizontal Stripe |
| actief gebied | 110.4(H)×62.1(V) mm |
| omtrek afm. | 136.38(H)×91.71(V) ×4.86(D) mm |
| luminantie | 800 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 20/15 (Typ.)(Tr/Td) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedrijfsmodus | - |
| ondersteunende kleur | 16.7M 66% NTSC |
| lichtbron | WLED [7S3P] , W/O Driver |
| gewicht | 63g (Typ.) |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | PCAP |
| interface-type | MIPI (4 data lanes) , 42 pins Connector |
| stroomvoorziening | 1.8/3.3V (Typ.)(VDDI/VCI) |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
